• Technology: Piezoelectric drop-on demand print-head
• Print Speed: 1,000 mm/s
• Print Height: 144 mm
• Print Length: 2,300 mm
• Throw Distance: Max. 10 mm
• Resolution: 180 dpi
• Ink Types: Solvent-based, Alternative Oil-based Inks
• Ink Colors: Black, Pigmented White, Pigmented Yellow, Red, Blue, Purple etc.
• Print Orientation: Any angle
• I/O Ports: Ethernet, 3 PIN NPN Photocell x 1, 4 PIN Shaft Encoder x 1
• Display: 2-line LCD with functional keypad
• Power: 12V – 3.3A
• No. of Print Heads: 2
• Ink Management: Low ink alarm & Ink consumption calculator
• Operating Temperature: 0°C to 45°C, Relative humidity: 20% – 80%
• Storage Temperature: -5°C to 50°C
• Net Weight: 3.6Kg
• Connectivity: Ethernet, Virtual RS-232, Optional Wi-Fi module available

Dimensions:

• Controller: 223 mm x 101 mm x 176 mm
• Ink supply: 165 mm x 145 mm x 72 mm
• Print head: 150 mm X 140 mm x 45 mm
